Traxxas: Stampede 2WD HD

Features

• Clipless Monster Truck Body
• High-Performance Waterproof XL-5™ Electronic Speed Control
• Titan 550 Motor
• TQ 2.4 GHz 2-Channel Radio System
• Includes 3000mah NiMh Battery and USB-C Charger

Specs

• Model Name:    Stampede 2WD HD w/USB-C

• Model Type:    Boats

• Model Speed:    30+ mph with 7-cell battery

• Model Skill Level:    1

• Scale:    1/10

• Weight:    4.08 pounds (1.85 kg)

• Length:    16.25 inches (413 mm)

• Width:    12.75 inches (324 mm)

• Front Track:    12.75 inches (324 mm)

• Rear Track:    12.75 inches (324 mm)

• Height:    9.5 inches (241 mm)
• Wheelbase:    10.63 inches (270 mm)

• Center Ground Clearance:    4 inches (102 mm)

• Drivetrain:    2WD

• Transmission:    Magnum 272™

• Differential Type:    Planetary steel gear

• Gear Ratio (Internal):    2.72 (final drive: 12.34)

• Gear Pitch:    48 pitch

• Servo(s):    2056 high-torque waterproof

• Radio System:    TQ™ 2.4 GHz 2-channel radio

• Battery Compartment Specs:    164 mm X 46 mm X 26 mm

Motor Specs

• Motor Name:    Titan® 12T 550

• Motor Type:    High-speed brushed motor

• Motor Weight:    8.47 ounces (240 g)

• Motor Length:    3.07 inches (78 mm) overall length, 2.25 inches (57 mm) can
• length

• Motor Diameter:    1.41 inches (36 mm)

• Motor Shaft Size:    3 mm

• Motor Connector Type:    Bullet

ESC Specs

• ESC Name:    Waterproof XL-5™ ESC with low-voltage detection

• ESC Type:    Brushed

• ESC Case Size:    1.23 inches (31 mm) / 2.18 inches (55 mm) / 1.04 inches (26 mm)

• ESC Weight:    2.44 ounces (69 g)

• Motor Connectors:    Bullet

• Battery Connectors:    Traxxas High-Current Connector

• ESC Power Wire:    14 gauge

What’s In The Box

• Stampede 2WD HD w/USB-C
• 3000mah NiMh Battery and USB-C Charger
• TQ 2.4 GHz 2-Channel Radio System

• Quick Start Guide

• High quality maintenance tools
